$20.00
In stock
Revolutionary Positive Stop Connectors for HELIAX corrugated coaxial cables require no special tools or torque wrenches, eliminating both guess work and time consuming measurements. Using standard wrenches and in less than one rotation, Positive Stop Connectors give the installer a clear visual and mechanical verification of a correct fit, sealing out water and sealing in excellent electrical performance.
L4TNM-PSA are Type N Male Positive Stop Connectors from Andrew / CommScope that help reduce connector attachment issues while ensuring excellent RF transmission line performance. Positive stop connectors are for use with HELIAX corrugated coaxial cables. They require no special tools or torque wrenches, thus eliminating both guess work and time consuming measuring. A standard wrench, and less than one rotation, is all that’s needed for these well-designed positive stop connectors.
Andrew L4TNM-PSAThey give installers a clear visual and mechanical verification of a correct fit, while sealing out water and helping to maintain excellent electrical performance. Positive stop connectors are waterproof, even unmated. Their clear verification eliminates the need to control torque levels and provides consistent attachment integrity and electrical performance. These positive stop connectors are ideal for 1/2 inch LDF4-50A, AL4RPV-50, HL4RPV-50 coaxial cables.
| Coax Construction | coaxial |
|---|---|
| Jacket Material | none |
| Conductor Material | bare copper |
| Conductor Type | solid conductor |
| Dielectric Material | air |
| Fire Rating | plenum |
| Flooded | no, not flooded over braid |
| Impedance | 50 ohm nominal impedance |
| Outdoor | no, not intended for outdoor use |
| Screen / Shield Type | special shield construction |
